Tables 36/37 — Wall Studs (Lower Storey)

AS 1684.2
Select inputs to see results

Inputs

Timber Grade
Table — Notching
Stud Spacing (mm)
Floor Joist Spacing — FJS (mm)
Roof Type
Upper Floor Load Width — UFLW (mm)
Required Roof Load Width — RLW (mm) (optional — highlights passing studs)

Maximum Roof Load Width

AS 1684.2 Table 36 — Not notched — Wind classification N1/N2

Size (D×B mm)Stud Height (mm)Max RLW (mm)
Select inputs above

Design Reference

Figure 6.12(b) — Wall studs, lower storey loadbearing walls
Figure 6.12(b) — Wall studs, lower storey loadbearing walls (AS 1684.2:2021)

Notes (AS 1684.2 Tables 36 & 37):

i) Table outputs are Maximum Roof Load Width (RLW) in mm for the given stud, stud spacing and loading conditions.

ii) Maximum roof load widths are based on a maximum total sheet roof, framing and ceiling mass of 40 kg/m², tile roof of 90 kg/m², and flooring mass of 40 kg/m².

iii) Table 36 = not notched studs; Table 37 = studs notched to 20 mm depth.

iv) Studs for internal non-loadbearing partitions (not carrying roof or floor loads) shall be as per Clause 6.3.5.

v) Large stud sizes may be nail-laminated vertically as per Clause 2.4.

vi) All stud walls shall be nogged at not more than 1350 mm centres.

vii) Wind classification N1/N2 only. For design parameters refer to Figure 6.12.
